| Type |
Four-stroke, water cooled, in-line, turbocharged/turbocharged and aftercooled |
Number of cylinders |
4 |
| Bore & stroke |
105×130 (mm) |
Displacement |
4.5 L |
| Oil consumption rate |
≤0.2 g/kW·h |
Noise |
≤100 dB(A) |
| Minimum fuel consumption rate |
195 g/kW·h |
Idle speed |
650±30 r/min |
Rotation
(facing the flywheel) |
Counter-clockwise |
Net weight |
600 kg |
| Dimensions (L×W×H) |
1065×819×1056 (mm) |
Model Portfolio Table
| Series |
Model |
Aspiration |
Rated power kW/Ps |
Speed
r/min |
Fuel system |
Emission |
Power rating |
| WP4 |
WP4C82-15 |
T |
60/82 |
1500 |
Mechanical pump |
/ |
P1 |
| WP4C95-18 |
T |
70/95 |
1800 |
Mechanical pump |
/ |
P1 |
| WP4C102-21 |
T |
75/102 |
2100 |
Mechanical pump |
/ |
P1 |
| WP4C102-15 |
TA |
75/102 |
1500 |
Mechanical pump |
/ |
P1 |
| WP4C120-18 |
TA |
88/120 |
1800 |
Mechanical pump |
/ |
P1 |
| WP4C130-21 |
TA |
95/130 |
2100 |
Mechanical pump |
/ |
P1 |
Remark: Product parameters and model portfolio are for reference only. Please contact relevant personnel for official information on delivery time and fishing boat model portfolio.
Product description
Safe and reliable
- The overhaul period of high-strength engine block, crankshaft, connecting rod and cylinder head is 12000h
- The high-quality suppliers of Weichai system are used. It is developed according to the high requirements of large displacement engines for reliability
- Rigorous and perfect test methods ensure the reliability of key parts and components
- Replace the filter without stopping
Strong power
- The torque reserve is as high as 20%-35%, the range of large torque section is wide, and the ships equipped with the engine will have good acceleration
Economical and fuel-efficient
- Reasonable allocation of oil pump, turbocharger, air intake and exhaust system; low oil consumption under common working conditions; good economical nature
- With shallow ω combustion chamber, the best cylinder clearance and swirl ratio, the fuel consumption rate is as low as 195g/kW•h
- Customized design for lower fuel consumption
Comfortable and environmentally friendly
- The NVH optimization for the whole engine effectively reduces vibration and noise
- There is no IMO emission requirement
Strong practicability
- LCD Internet instrument can be selected to monitor engine operating parameters in real time, so as to realize automatic alarm and stop
- It is suitable for marine engines such as passenger ships, cargo ships, public service ships, fishing boats and tourist ships
